GL206A

GL206A

High-Powered Active Line Array Speaker System with DSP for Versatile Sound Reinforcement


The GL206A is a versatile, high-performance active line array speaker designed for various sound reinforcement applications. It features a compact and lightweight design with a high-strength PP composite material cabinet. The speaker offers exceptional audio quality with built-in DSP for precise control and easy integration into different setups. Its robust construction, advanced features, and multiple configuration options make it ideal for large touring shows, medium-sized stadiums, multifunction halls, churches, and other small to medium-sized venues.


Prev Product Next Product

Product Description

  • Interior Protection:

    • The inside grill is surrounded by foam for added protection.

  • Exterior Durability:

    • The shell is made of solid, high-quality, moisture-proof birch plywood (G series).

    • The GL206A cabinet is made of PP composite material, lightweight yet sturdy.

    • Grill and accessories are double-layer powdered for dustproofing, UV protection, and anti-corrosion.

  • Ergonomic Design:

    • Ergonomically designed handles on both the broadside enhance portability.

  • Audio Features:

  • GL206A:

    • Features a 3" neodymium tweeter and two 6.5" woofers for a dynamic combination with a large dynamic margin and a lower crossover point.

    • Maximum SPL: 130 dB

    • Coverage: 100° x 10°

    • Active line arrays in configurations of 4+1, 8+2, and 16+4 can be combined without additional amplifiers and processors.

    • Built-in high-power dual-channel Class D switching power amplifier module.

    • Built-in DSP module with gain, crossover, equalization, delay, pressure limit, program memory, and preset recall functions.

    • Amplifier panel with RS485 network interface for easy operation and online control of speaker groups.

  • G Series:

    • Passive line array cabinet with directivity control, evenly distributed sound field, and appropriate sound pressure ratio.

    • Designed for active integration with main speakers and subwoofers, featuring a compact size and lightweight.

  • Special Features:

    • The trademark on the speaker mesh panel with lighting effect.

    • Factory DSP with three stored debugging programs for "plug and play" operation.

    • Multiple mounting options: can be stacked, hung, and used in various small and medium-sized venues.

    • Easy installation and debugging, flexible and versatile multi-combination application.

  • Applications:

    • Large touring shows

    • Medium-sized stadiums

    • Multifunction halls

    • Churches


Product Parameter

Model: GL 206A Type: ACTIVE TWO-WAY LINE ARRAY MODULE
Power Source: ACTIVE Components: 2 x 6.5" Neodymium mid-bass driver, 1 x 3" Neodymium compression driver
Impedance in ohm: - H Coverage per Element: 100°
V Coverage per Element: 10° Frequency Response Range (-): 70 Hz(-10dB)
Frequency Response Range (+): 20k Hz(-10dB) RMS Power(W): 400W(MLF), 150W(HF)
SPL max. (1m, Free field): 130 dB Built-in Crossover: NO
Housing: PP Composite Hanging Point(s): 3
Elements Angle: 10° Elements up to (single array): -
Height in mm: 207 mm Width in mm: 470 mm
Depth in mm: 341 mm Weight in kg: 15 kg
